CIRCULAR MOVEMENT
ROTATOR TP08
The TP08 rotator from WICREATIONS is a robust and powerful rotational machine, specifically designed for heavy-duty applications. Engineered for mounting securely on a 750mm truss, the TP08 operates exclusively in a horizontal position ensuring smooth, stable and precisely controlled movement.
As the WI TP08 is designed to rotate voluminous and heavy objects around a vertical axis, it is the ideal solution for demanding indoor as well as outdoor events from live stages, venues and entertainment to industrial use. Wherever it's deployed, it will deliver precision and consistent performance even under the challenging conditions.
The TP08 fully complies with the rigorous DIN 13814, DIN 56950 and EN 1993:2004 standards thus guaranteeing top-tier safety, durability and structural integrity. It is moreover smartly engineered for seamless integration into complex setups and optimized for superior performance in large-scale rotational applications.
Downloads
Technical details and 3D downloads available for experts and designers
Go to WIcommunityMAIN FEATURES
Optimized Load Capacity & Balance
- The maximum load depends on the size of the object being turned around. This is calculated separately for each project.
- The object’s mass must be balanced and centered to the rotation axis.
TECHNICAL SPECIFICATIONS
| Own weight | 960 kg |
| Max. speed | 6 rpm |
| Max. axial load | 13 T |
| Max. tilting moment | 24250 kgm |
Check the load tables in the pdf.
DIMENSIONS
