CIRCULAR MOVEMENT
TURNTABLE TP02
The TP02 turntable is a plug-and-play solution engineered to minimize load-in and load-out times, delivering efficiency and convenience. With just a few components required for assembly - 2 parts for the 2-meter table and 20 parts for the 5-meter table - setup is quick and straightforward.
Once installed, the TP02 is immediately operational and seamlessly integrates with our advanced motion control software, giving you complete control at your fingertips.
At its core, the TP02 features a built-in slip contact, enabling an infinite rotation loop. This ensures uninterrupted power and data supply, making it the perfect fit for any production system requiring consistent connectivity.
Downloads
Technical details and 3D downloads available for experts and designers
Go to WIcommunityMAIN FEATURES
This turntable features an exceptionally compact installation height, reaching a maximum of just 350 mm. To ensure it fits seamlessly into various setups, its height is adjustable between 295 mm and 350 mm. The TP02 model is designed with a 2-meter diameter inner table, providing ample space for performance or technical use. All essential technical components required to enable rotation are neatly integrated within this central part. Additionally, there is an option to expand the system to a larger 5-meter turntable, allowing for greater versatility.
The table guarantees highly precise positioning, achieved through a robust toothed gear drive system. Stability is ensured by a full circle of polyamide heavy-duty wheels, each paired with a stainless steel guiding wheel for optimal performance. This reliable wheel system keeps the table steady even under demanding conditions. To secure the turntable to other stage elements, it is equipped with 12 solid steel connection elements. This design makes the TP02 a durable and adaptable solution for any stage environment.
TECHNICAL SPECIFICATIONS
2m Turntable
| Own weight | 250 kg |
| Max. static load | 500 kg/m² |
| Max. dynamic load | 100 kg/m² |
| Speed, With a runner of 1:60 | 2,2 rpm |
| Edge Speed | 227 mm/sec |
| Max. Load | 1500 kg |
5m Turntable
| Own weight | 900 kg |
| Max. static load | 500 kg/m² |
| Max. dynamic load | 100 kg/m² |
| Speed, With a runner of 1:60 | 2,2 rpm |
| Edge Speed | 568 mm/sec |
| Max. Load | 2000 kg |
